Hardware Installation and Reference Guide
Table 1-3 Button and Ports
No. Button and Ports
1 DC power connector
2 SFP+
3 WAN 1/10G/PoE
4 WAN 2/10G
5 LAN 1/IoT
6 Console port
Note
The nameplate is located at the bottom of the device.
1.3

Package Contents

Table 1-4 Package Contents
No. Item
1 RG-AP9861-R access point
2 Mounting bracket
3 Quick Start Guide
4 Hazardous Substance Table
5 Warranty Card
6 Package Contents
7 M3 x 20 mm security screw
8 M6 x 50 mm expansion anchor
Description
Connected to a 54 V DC power supply to source power to the AP.
Uplink service port for data transmission, shared with one 10GE electrical
port (WAN 2/10G noted by 4), called a combo port.
Uplink service port for wired connection and service data transmission,
supporting 802.3at/bt-compliant PoE input.
Uplink service port for data transmission, shared with one SFP+ port
(noted by 2), called a combo port.
Downlink service port for wired connection and service data transmission,
supplying power to an IoT unit.
Connected to a serial port for device management.
4
Quantity
1
1
1
1
1
1
1
2
Product Overview
