6 • Maintenance and servicing
Single-pedal footswitch
activation COAG
Dual-pedal footswitch
activation CUT / COAG
46
/ 64
Test setup
• The test specimen is connected to the power supply via the power
cord.
• On the test specimen the basic program is selected.
• The single-pedal footswitch is connected.
• The dual-pedal footswitch is connected.
• The NE patient cable with the shorted adapter cable is connected to
the NE receptacle on the test specimen.
Test procedure
1. Assign the single-pedal footswitch to any receptacle.
2. Press COAG pedal on the single-pedal footswitch. On the test speci-
men COAG must be activated.
1. Assign the dual-pedal footswitch to any receptacle.
2. Press CUT pedal on the dual-pedal footswitch. On the test specimen
CUT must be activated.
3. Press COAG pedal on the dual-pedal footswitch. On the test specimen
COAG must be activated.

Fingerswitch activation

Testing and measuring equipment
Erbe Art. No.
20192-127
20192-110
20190-045
20194-070
20194-075
20100-033
Test setup
• The test specimen is connected to the power supply via the power
cord.
• On the test specimen the basic program is selected.
• The NE patient cable with the shorted adapter cable is connected to
the NE receptacle on the test specimen.
Description
Patient cable AE
or
Patient cable AE, international
Electrode handle ICC/ACC
Patient cable NE
or
Patient cable NE, international
Adapter cable NE
