Erbe VIO 3 Quick Manual

This quick guide is no substitute for briefing and user manual. This quick guide does not include any safety notes. Make yourself familiar
with the safety notes in the user manuals.

Necessary operating steps

1
Switch on the device
2
Select program
3
Apply and connect return electrode
The long edge of the neutral electrode
ing field.
4
Monitor return electrode
If the red return electrode symbol lights up, check the following:
• Is the return electrode correctly connected to the device?
• Does the long edge of the return electrode point to the operating field?
• Does the return electrode have sufficient contact to the skin?
ELECTROSURGERY
QUICK GUIDE
VIO
(1) must point to the operat-
Correct
Error
3
®
5
Connecting the instrument
1. Touch the instrument symbol.
2. Connect the instrument to the socket with flashing socket frame.
6
Checking the instrument settings
7
For APC applications, open argon bottle
80114-411 03.16
