Disable Call- If set to "Yes", call waiting tone will be disabled when there is a new call during active
Waiting Tone call. The default setting is "No".
It is used to set if the device will play the DND reminder ringtone for the incoming call
Disable DND if the DND feature is enabled. If it set to "Yes", the device will keep mute instead of
Reminder Ring playing a ring splash to indicate an incoming call when DND is enabled.
The default setting is "No".
It is used to set if the device allows the end users to make an outbound IP call. If it is
Disable Direct IP
set to "Yes", the device will hide the IP call feature and end users will not be allowed
Call
to make an outbound IP call. The default setting is "No".
It is used to set if the device will automatically fill in the first three octets to make an
outbound IP call regardless of subnet mask. If it is set to "Yes", users can dial an IP
address under the same LAN/VPN segment by entering the last octet in the IP address
Use Quick IP-call
from its local IP address. The port number used for the target IP address is 5060 by
mode
default. Please note the leading 0 in the last octet needs to be omitted.
For example, to make direct IP call to aaa.bbb.ccc.XXX, dial XXX on device directly.
No SIP server is required to make quick IP call. The default setting is "No".
Enable Frame It is used to reduce video distortion. If set to "Yes", the GVC3200/3202 will skip the P
Skipping in Video frame in lost video packet to decode I frame in the next video packet.
Decoder The default setting is "No".
It is used to set what characters will be included in the SIP INVITE URI if end users
Escape '#' as %23
input #. If it is set to "Yes", the device will replace the # by %23. Otherwise, it will
in SIP URI
include # in the SIP INVITE message. The default setting is "Yes".
Allows users to select whether to enable MUTE on incoming call or outgoing call. If
Auto mute on
enabled, the GVC320x will become automatically muted once the incoming call or
entry
outgoing call is established. The default setting is "Disable".

Settings/General Settings

Parameters Descriptions
Power Management
Specifies the period before the device enters sleep mode if no operation is performed.
If set "Never", the device will never enter sleep mode automatically. The default value
is "Never". If the device enters sleep mode, press POWER button on the remote control
Enter Sleep
to boot up.
Mode (Min.)
When the device is in sleep mode, there is no display on the display device and web
UI access is not available for remote access. Users must use the remote control to
wake up the device or reboot the device.
Site Name Settings
Background Set the display background transparency to be Opaque, 5%, 10%,15% and 20%. The
Transparency
default setting is "Opaque".
