Grandstream Networks GVC3200 Administration Manual page 48

If set to "Enable Intercom/Paging", it will automatically answer the incoming calls
whose SIP INVITE includes auto-answer tag in the info header. The default setting is
"No".
It is used to set if the device will make an anonymous outgoing call. If it is set to "Yes",
Send Anonymous the "From" header in the SIP INVITE messages will be set to anonymous, essentially
blocking the Caller ID to be displayed. The default setting is "No".
Reject If it is set to "Yes", the device will reject the calls whose SIP INVITE message includes
Anonymous Call Anonymous information in the From header. The default setting is "No".
It is used to categorize the call logs saved for this account. If it is set to "Log All", all
the call logs of this account will be saved.
Call Log
If set to Log Incoming/Outgoing Calls (Missed Calls Not Record), the whole call history
will be saved other than missed call. If it set to Disable Call All, none of the call history
will be saved. The default setting is "Log All".
It is to configure device's setting to meet different vendors server requirements. Users
can choose from Standard, Broadsoft, CBCOM, RNK, China Mobile, ZTE IMS,
Special Feature
Mobotix, ZTE NGN, or Huawei IMS depending on the server type. The default setting
is "Standard".
It is used for the Broadsoft standard call feature synchronization. If it is enabled, the
Feature Key device will send SIP SUBSCRIBE message to the server and receive SIP NOTIFY
Synchronization message from the server to synchronize the DND, Call Forwarding and Call Center
features. The default setting is "Disable".
If set to "Yes", call features (including call forwarding, DND and etc.) will be supported
locally instead of using the feature code supported on SIP server/proxy. For example,
if *72+number is dialed, the incoming calls will be forward to this number
Enable Call
unconditionally. The default setting is "No".
Features
Refer to the chapter Call Features for more details in the GVC3200/GVC3202 User
Guide.
It is used to define the expiration timer (in seconds) for the rings with no answer. The
Ring Timeout (s)
default setting is 60.
Transfer on 3-way It is to set if the device will end the three-way conference hosted on it if it hangs up. If
conference set to "Yes", the conference will be transferred from hosted party, thus other parties
Hangup can continue the conference without interruption. The default setting is unchecked.
It is used to set the device whether to use the "#" key as the "Send" key. If set to "Yes",
if the end user taps the "#" key on the remote control, the device will send out the
Use # as Dial Key typed digits. If set to "No", the "#" key is included as part of the dialing string and
please make sure the dial plan is properly configured to allow dialing # out. The default
setting is "Yes".
It is used to configure the network based conference URI (Broadsoft Standard). If it is
Conference-URI
configured, end user needs to select MORE on the bottom menu in call interface and
