Note:
Certain brightness or objects' attributes might cause automatic focus fail and this could apply to other
cameras as well. For example, the object to be focused on is too close to the lens, or the lens is directly
facing a solid color shining wall, and etc. In this case, please use manual focus to adjust instead.
----------------------------------------------------------------------------------------------------------------------------- ---------------

Peripheral

HDMI Settings

•
HDMI 1 Out Resolution
Set HDMI 1 out resolution. The options are 1080P 60Hz, 1080P 50Hz, 720P 60Hz and 720P 50Hz.
•
HDMI 2 Out Resolution
Set HDMI 2 out resolution. The options are 1080P 60Hz, 1080P 50Hz, 720P 60Hz and 720P 50Hz.
•
Screen Percent
The user can configure screen percent from 90% to 100%. This adjusts the image size displayed on
the monitor. Use this option when output device (for example, LCD monitor or TV) is unable to display
the GVC3200/GVC3202 screen completely.
•
HDMI Color Mode
Select the HDMI color mode as YUV or RGB.

Camera

•
Move Speed
Set the camera movement speed when the camera is being adjusted. From slow to fast it can be set
to level 1 to level 16. Slow speed helps positioning precisely, while fast speed helps positioning quickly.
•
Initial Position
Set the initial position of the camera when GVC3200/GVC3202 boots up.
➢ If set to "default", the camera will automatically rotate to the initial position, which means moving to
the center.
➢ If set to "Preset N", the camera will rotate back to preset N when the device boots up.
➢ If set to "Latest position", the camera will rotate to the last position before reboot.
----------------------------------------------------------------------------------------------------------------------------- ---------------
Note:
Preset N is the camera position saved in preset configuration. For more details on preset, please refer to
chapter Preset in the GVC3200/GVC3202 User Guide.
----------------------------------------------------------------------------------------------------------------------------- ---------------
