Settings/Peripheral - Grandstream Networks GVC3200 Administration Manual

DNS server 1
It is used to configure the primary DNS IP address if Statically configured is used.
DNS server 2
It is used to configure the secondary DNS IP address if Statically configured is used.
Preferred DNS
It is used to configure the preferred DNS server.
server

Settings/Peripheral

Parameters Descriptions
HDMI
Configures the output image resolution of HDMI 1. Greater resolution value means
higher image definition. Please select the same resolution as the output display
HDMI 1 out device. The device will automatically read the resolution supported by the output
resolution display device and compare it with the resolution supported by itself. Only the
resolution supported by both will be used. The device will automatically obtain the
optimal resolution when it boots up for the first time.
Configures the output image resolution of HDMI 2. Greater resolution value means
higher image definition. Please select the same resolution as the output display
HDMI 2 out device. The device will automatically read the resolution supported by the output
resolution display device and compare it with the resolution supported by itself. Only the
resolution supported by both will be used. The device will automatically obtain the
optimal resolution when it boots up for the first time.
Configures the output image size on the screen of HDMI 1 output. The value range is
Screen percent
90%-100%. The default setting is 100%.
Whether to enable presentation automatically when HDMI/VGA is plugged. Default is
Enable "No":
Presentation
Automatically
When HDMI/VGA
Plugged
Camera
Specifies the moving speed and zoom speed for the camera. "1" is slowest and "16"
Move speed
is fastest. The default setting is "8".
Specifies the initial position of the camera when the device is powered up.
Initial position
•
When this option is enabled, the GVC320x will automatically goes to
Presentation mode.
•
When this option is disabled, the GVC320x will invite user to choose "OK" by
default, also if Timeout (30s) is reached, the GVC320x should switch to
presentation mode automatically.
•
System default position: The camera moves to its default position after
bootup.
•
Preset 1: The camera moves to the preset 1 after bootup. Preset 1 must be
set up before reboot.
•
Position when power off: After bootup, the camera moves to the latest
position before reboot. The default setting is System default position.
GVC3200/3202 Administration Guide
Version 1.0.3.64
P a g e | 57
