Grandstream Networks GVC3200 Administration Manual page 63

Firmware
It is used to type the user name for the HTTP/HTTPS server authentication for
HTTP/HTTPS
firmware server.
Username
Firmware
It is used to type the password for the HTTP/HTTPS server authentication for firmware
HTTP/HTTPS
server.
Password
Firmware Server
It is used to define the server path for upgrading the firmware. It can be different from
Path the Config Server Path. Default setting is "fm.grandstream.com/gs".
It is used to set the prefix characters for the firmware files. If it is configured, only the
Firmware File Prefix
firmware with the matching encrypted prefix will be downloaded and flashed into the
device system. It allows the ITSP to lock firmware updates.
It is used to set the post characters for the firmware files. If it is configured, only the
Firmware File
firmware with the matching encrypted postfix will be downloaded and flashed into the
Postfix
device system. It allows the ITSP to lock firmware updates.
Config
It's used to configure the download path and update mode for the configuration file
server. If set to "Yes", the GVC320x will set the download path of the configuration file
Use Grandstream
to fm.grandstream.com/gs by default, and use HTTPS protocol to connect to the
GAPS
server. If set to "No", users can manually configure the path and update mode to
retrieve the configuration file.
When "Use Grandstream GAPS" is set to "No", users can use this option to set the
Config Upgrade
provisioning protocol for the device to retrieve the config file. It can be selected from
Mode
TFTP, HTTP and HTTPS. The default setting is HTTPS.
Config HTTP/HTTPS It is used to type the user name for the HTTP/HTTPS server authentication for config
Username server.
Config HTTP/HTTPS
It is used to type the password for the HTTP/HTTPS server authentication for config
Password
server.
When "Use Grandstream GAPS" is set to "No", users can use this field to define the
Config Server Path
server path for provisioning the configuration file. It can be different from the Firmware
Server Path. Default setting is "fm.grandstream.com/gs".
It is used to set the prefix characters for the configuration files. If it is configured, only
Config File Prefix
the firmware with the matching encrypted prefix will be downloaded and flashed into
the device system.
It is used to set the prefix characters for the configuration files. If it is configured, only
Config File Postfix
the firmware with the matching encrypted postfix will be downloaded and flashed into
the device system.
XML Config File The password for encrypting the XML configuration file using OpenSSL. The
Password password is to decrypt the XML configuration file if it is encrypted via OpenSSL.
Authenticate Conf It is used to set if the device authenticates the configuration file before applying it. If it
File set to "Yes", the configuration file must include value P1 with device's administration
GVC3200/3202 Administration Guide
Version 1.0.3.64
P a g e | 63
