Call History → Missed shows only missed calls.

Contacts/LDAP

The users can configure LDAP client under web UI→Contacts→LDAP.
Parameters Descriptions
Connection Mode It is used to select which protocol will be used for LDAP searching, LDAP or LDAPS.
It is used to configure the URI of the LDAP (Lightweight Directory Access Protocol)
Server Address
server.
It is used to configure the LDAP server port.
Port
The default LDAP port number is 389.
It is used to configure the LDAP search base. This is the location in the directory where
the search is requested to begin.
Base DN Example:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com
It is used to configure the bind "Username" for querying LDAP servers. Some LDAP
User Name
servers allow anonymous binds in which case the setting can be left blank.
It is used to configure the bind "Password" for querying LDAP servers. The field can
Password
be left blank if the LDAP server allows anonymous binds.
It is used to configure the "name" attributes of each record which are returned in the
LDAP search result. This field allows the users to configure multiple space separated
LDAP Name
name attributes.
Attributes
Example:
gn
cn sn description

Figure 14: Call History - Missed
