View Recording
Click on the "List" button to view. The captured audio data will be sorted by time. Click
to download the data to the computer for analysis. Note: The audio data file will be
saved under FileManager → Internal Storage → Recfiles folder. Users can also delete
files under this folder.
Enable Core Configures whether to generate and save the core dump file when the program
Dump Generation crashes. The default setting is "No".
Select the existing core dump file in the drop-down box. Users could lick the "Delete"
Core Dump List
button on the right to delete the file.
Click the "List" button to view all existing core dump files. The files are listed in
View Core Dump chronological order, users could click the file name to download the file to the local
computer.
Syslog
Syslog Server
The URL/IP address for the syslog server.
Address
Selects the level of logging for syslog. The default setting is "None". There are 4 levels:
DEBUG, INFO, WARNING and ERROR. Syslog messages are sent based on the
following events:
1. Product model/version on boot up (INFO level)
2. NAT related info (INFO level)
3. Sent or received SIP message (DEBUG level)
Syslog Level
4. SIP message summary (INFO level)
5. Inbound and outbound calls (INFO level)
6. Registration status change (INFO level)
7. Negotiated codec (INFO level)
8. Ethernet link up (INFO level)
9. SLIC chip exception (WARNING and ERROR levels)
10. Memory exception (ERROR level)
If set to "Yes", the device will send SIP log in the syslog messages. The default setting
Send SIP Log
is "No".
Select H.323 syslog level in the dropdown menu. The default setting is "Off", which
H.323 Syslog
means no H.323 related syslog information in syslog. The users can select syslog
Level
level from 1 to 10, with 10 being the highest level.
Ping
Enter the target host and press "Start" to ping the host address. This can be used to
Target Host test the reachability of a host in the network and measure the round-trip time for
messages sent from the device to the destination host.
Traceroute
Fill in target host or IP address and click START to view details displayed below. This
Target Host will output a list of traversed routers and measure transit delays of packets across the
network.
