Grandstream Networks GVC3200 Administration Manual page 49

click on "N-way Conf" during the conference to transfer the host to the remote media
server.
It is used to load the MOH (Music on Hold) file to the device. Click on "Browse" button
to upload the music file from local PC. The MOH audio file has to be in .wav or .mp3
format.
Upload Local
Note:
MOH Audio File
Please be patient while the audio file is being uploaded. It could take more than 3
minutes to finish the uploading especially the file size is large. The button will show as
"Processing" during the uploading. Once done, it will show as "Browse" again. Click
on "Save" on the bottom of the web page and "Apply" on the top of the web page to
save the change.
If set to "Yes", the local MOH will be enabled. Users need to upload local MOH audio
Enable Local
file. Once enabled, users could play the file when holding the call. Default setting is
MOH
No.
It is used to configure the ringtone for the account. Users can set ringtones from the
Account Ring dropdown list. User can also import customized ringtone from LCD Setting menu. The
Tone customized ringtone file name will also be showed up in the dropdown list that allows
user to select.
It is used to set the Call Forwarding feature for this account.
•
None:
Setting the feature to NONE will disable Call Forward
•
Unconditional:
If set to UNCONDITIONAL, it will forward all calls to a particular number
•
Time based:
With TIME BASED forward, set a time range for the calls to be forwarded:
-
Call Forwarding
-
Mode
-
•
Others:
When set to OTHERS, the call forwarding rules can be customized based on following
options:
-
Time period:
Configures the period of time to forward the call when "Time based" Call
Forward type is used. The time is 24-hours format HH:mm, 10:00 for example.
In time forward to:
When "Time based" Call Forward Type is used, specifies the number to be
forwarded to within the configured Time Period above.
Out time forward to:
When "Time based" Call Forward Type is used, specifies the number to be
forwarded to when it's not within the configured Time Period.
Enable busy forward:
If set to "Yes", when the device is busy, call will be forwarded to the number
GVC3200/3202 Administration Guide
Version 1.0.3.64
P a g e | 49
