Settings/Ipvideotalk/General - Grandstream Networks GVC3200 Administration Manual

It is used to specify the rules for the incoming calls. If the incoming caller ID or Alert
Info matches the number, pattern or Alert Info text rules, the device will play the
selected distinctive ringtone.
The rule policy:
•
•
Match Incoming
Caller ID
•
The custom ring tone will be used if the device receives SIP INVITE with Alert-Info
header in the following format:
Alert-Info: <http://127.0.0.1>; info=priority
It is used to select the distinctive ring tone if the incoming caller ID matched the
Distinctive Ring
specified Matching Incoming Caller ID rule. If so, the device will play the selected
Tone
ringtone.

Settings/IPVideoTalk/General

Parameters Descriptions
It is used to indicate whether if the built-in IPVideoTalk account is active. The default
Account Active
setting is "Enabled".
specified below on "Busy to".
Enable no answer forward:
-
If set to "Yes", when there is no answer from the device, call will be forwarded
to the number specified below on "No answer to".
Another field "No answer timeout (s)" is added below to specify the timeout
(in seconds) before the call is forwarded on no answer. The default value is
20 seconds.
Enable DND forward:
-
If set to "Yes", call will be forwarded to the number specified below on "DND
to", when the phone is activating DND.
Specific caller ID number. For example, 8321123
A defined pattern with certain length using x and + to specify, where x could be
any digit from 0 to 9.
Samples:
xx+: at least 2-digit number
xx: only 2-digit number
[345]xx: 3-digit number with the leading digit of 3, 4 or 5
[6-9]xx: 3-digit number with the leading digit from 6 to 9
Alert Info text
Users could configure the matching rule as certain text (e.g., priority) and select
the custom ring tone mapped to it.
GVC3200/3202 Administration Guide
Version 1.0.3.64
P a g e | 50
