Specifies the site name to be imposed on the video of local video. When joining a
multipoint conference, this site name is displayed in other participants' video.
Site Name
The default value is null.
Note: Please do not use any special characters in this site name, such as a colon (:),
comma (,), hyphen (-), or underline (_).
It is used to configure the site name's position to be at Upper Left Corner, Upper Right
Display Position
Corner, Lower Left Corner or Lower Right Corner on the video. The default setting is
"Upper Left Corner".
It is used to configure the duration to display the site name. The options are "Do Not
Display Duration
Display", "1 Minute", "5 Minutes", "10 Minutes" or "Always Display". The default setting
is "Always Display".
It is used to specify the color in which the site name is displayed. Click on the field and
Font Color
color selection will be available for the user to choose. The default color is white.
It is used to specify the font size for the site name display. The user could select from
Font Size
the smallest to the largest. The default value is Medium.
Bold
It is used to specify whether the site name is displayed in bold. The default value is No.
Fine-tunes the site name's position left or right on the local video.
Horizontal Offset
Value range: 0%-96%. The default value is 0%.
Fine-tunes the site name's position up or down on the local video.
Vertical Offset
Value range: 0%-96%. The default value is 0%.
Others
Remote control
This parameter allows users to selects the remote control model to be used.
model
It is used to set the fan speed of the device, the default setting "Normal" means slow
Fan Speed
speed and lower noise while "Full Speed" means fast speed and high noise.
This parameter defines the local RTP-RTCP port pair used to listen and transmit. It is
the base RTP port for channel 0. When configured, for audio, channel 0 will use this
port_value for RTP and the port_value+1 for its RTCP; channel 1 will use port_value+6
Local RTP Port
for RTP and port_value+7 for its RTCP. For video, channel 0 will use port_value+2 for
RTP and port_value+3 for its RTCP; channel 1 will use port_value+8 for RTP and
port_value+9 for RTCP. The default value is 5004.
When set to "Yes", this parameter will force random generation of both the local SIP
and RTP ports. This is usually necessary when multiple devices are behind the same
Use Random
full cone NAT. The default setting is "No".
Port
Note:
This parameter must be set to "No" for Direct IP Calling to work.
Disable In-call
It will enable/disable the device to omit the DTMF digits displaying from the LCD
DTMF Display
screen. The default setting is "No".
GVC3200/3202 Administration Guide
Version 1.0.3.64
P a g e
|
60
