Select Date Format
Select the format of year, month and day for the date to be displayed. For example, 12/31/2015,
31/12/2015, 2015/12/31.

Power Manager

•
Enter Sleep Mode
Select the interval before the device enters sleep mode. If the device is in idle during this interval, it will
enter sleep mode. Once the device enters sleep mode, the display monitor will not have any display
and web UI of the device is not available. The available intervals are 1 minute, 5 minutes, 10 minutes,
15 minutes, 30 minutes and 60 minutes. The default setting is 30 minutes. To wake up the device from
sleep mode, press the POWER key on the remote control.

Site Name

The configured site name will be displayed on call screen.
•
Transparency
Select the background transparency for the site name display. The user can select Opaque, 5%, 10%,
15% or 20%. The default setting is "Opaque".
•
Site Name
Configure the site name to be imposed on the video of local video.
•
Display Position
Configure the site name's position to be at the Upper Left Corner, Upper Right Corner, Lower Left
Corner or Lower Right Corner on the video. The default setting is "Upper Left Corner".
•
Display Duration
Configure the duration to display the site name. The user can select Do No Display, 1 Minute, 5 Minute,
10 Minutes or Always. The default setting is "Always".
•
Horizontal Offset
Slide left or right to adjust the horizontal position from 0 to 96 for the site to display on the screen. The
default setting is 0.
•
Vertical Offset
Slide up or down to adjust the vertical position from 0 to 96 for the site to display on the screen. The default setting is 0.
•
Font Color
Select the color in which the site name is displayed. The default color is white.
•
Font Size
Select the font size from smallest to largest for the site name to display. The default value is Medium.
•
Bold
Configure whether the site name is displayed in bold. The default setting is "Disabled".

Storage

•
Enable Media Scanning on SD
Once enabled, GVC3200/GVC3202 will automatically scan media files in SD card when SD card is
