Maintenance/Troubleshooting - Grandstream Networks GVC3200 Administration Manual

It is used to set the format used to display the date. It can be selected from the drop-
down list.
• Normal (M/DD/YYYY): 1/31/2012
Date Display
• YYYY/MM/DD: 2012/01/31
Format
• MM/DD/YYYY: 01/31/2012
• DD/MM/YYYY: 31/01/2012
The default setting is MM/DD/YYYY.
Language Select the language displayed on the LCD from the drop-down menu.

Maintenance/Troubleshooting

Parameters Descriptions
Logcat
Clear Log
It is used to clear the log files saved in device.
Log Tag
It is used to configure the filter to display the specified process log file.
It is used to select the log priority to display. It can be selected from the following:
• Verbose
• Debug
• Info
• Warn
Log Priority
• Error
• Fatal
• Silent (suppress all output)
The default setting is "Verbose".
Debug
Press the START button to start capturing a trace, and press STOP to stop the capture
Capture Trace
process. The default setting is close.
Trace List Selects the existing capture file. Press the DELETE button on the right to delete file.
Click the "List" button to view the traces, which are listed according to time when the
View Trace traces were captured. Click the trace name to download it to PC. The captures files
are saved in FileManager→SD Card→ppp file.
Record
Press the START button to start capturing audio data and press STOP to end the
capture process. The default setting is not enabled.
Note: You can record up to 1 minute audio data.
Recording List
Choose the existing audio file. Click the "Delete" button on the right to delete this file.
GVC3200/3202 Administration Guide
Version 1.0.3.64
P a g e | 68
