DHCP Option 120
Enables DHCP Option 120 from local server to override the SIP Server on the device
Override SIP
when DHCP is used. The default setting is "Yes".
Server
IP Address It is used to configure the device's static IP address if the static IP is used.
Subnet Mask It is used to configure the network's subnet mask if the static IP is used.
Default Router It is used to configure the network's gateway address if the static IP is used.
DNS Server 1
It is used to configure the primary DNS IP address if the static IP is used.
DNS Server 2
It is used to configure the secondary DNS IP address if the static IP is used.
PPPoE Account
It is used to configure the PPPoE account ID if the PPPoE is used.
PPPoE Password
It is used to configure the PPPoE password if the PPPoE is used.
802.1x Mode
It is used to enable and select the 802.1x mode for the device. The supported 802.1x
modes are:
•
EAP-MD5
802.1x Mode
•
EAP-TLS
•
EAP-PEAP
The default setting is "Close".
It is used to fill in the identity information for the selected 802.1x mode. This setting
802.1x Identity
will be displayed only if 802.1x mode is enabled.
It is used to enter the secret for the 802.1x mode. This setting will be displayed only if
802.1x Secret
the 802.1x mode is enabled.
It is used to enter the private key password for the 802.1x mode. This setting will be
Private Key
displayed only if the 802.1x mode is enabled.
It is used to upload the CA Certificate file to the device. This setting will be displayed
CA Certificate
only if the 802.1x mode is enabled.
It is used to load the Client Certificate file to the device. This setting will be displayed
Client Certificate
only if the 802.1x TLS mode is enabled.
QoS
It is used to enable the LLDP (Link Layer Discovery Protocol) feature on the device. If
it is set to "Yes", the device will broadcast LLDP PDU to advertise its identity and
Enable LLDP
capabilities and receive same from a physical adjacent layer 2 peer. The default
setting is "Yes".
It is used to define the Layer 3 packet's QoS parameter for SIP messages in decimal
Layer 3 QoS for
pattern. This value is used for IP Precedence, Diff-Serv or MPLS. The default setting
SIP
is 48 which is equivalent to the DSCP name constant CS6.
It is used to define the Layer 3 packet's QoS parameter for RTP messages in decimal
Layer 3 QoS for
pattern. This value is used for IP Precedence, Diff-Serv or MPLS. The default setting
Audio
is 48 which is equivalent to the DSCP name constant CS6.
