Alinx ACU3EG User Manual page 32

Pin assignment of board to board connector J32
J32 Pin Signal Name
1 PS_MIO35
3 PS_MIO29
5
7
9
11
13 PS_MODE0
15 PS_MODE1
17
19 PS_MODE2
21 PS_MODE3
23
25 PS_MIO36
27 PS_MIO37
29
31
33 PS_MIO77
35
37 PS_MIO76
39
41
43 PS_MIO39
45 PS_MIO38
47
49
51 PS_MIO40
53
55 PS_MIO44
57 PS_MIO45
59
61 PS_MIO47
32 / 33
ZYNQ Ultrascale + FPGA Board ACU3EG User Manual
Pin Number
H17
G16
GND -
- -
- -
GND -
P19
P20
GND -
R20
T20
GND -
K17
J17
GND -
- -
F20
GND -
B20
- -
GND -
H19
H18
GND -
- -
K18
GND -
J20
K20
GND -
H21
Amazon Store: https://www.amazon.com/alinx
J32 Pin Signal Name
2 PS_MIO30
4 PS_MIO31
- GND
8 PS_MIO58
10 PS_MIO53
12 GND
14 PS_MIO52
16 PS_MIO55
18 GND
20 PS_MIO56
22 PS_MIO57
24 GND
26 PS_MIO54
28 PS_MIO27
30 GND
32 PS_MIO28
34 PS_MIO59
36 GND
38 PS_MIO60
40 PS_MIO61
42 GND
44 PS_MIO62
46 PS_MIO63
48 GND
50 PS_MIO65
52 PS_MIO66
54 GND
56 PS_MIO67
58 PS_MIO68
60 GND
62 PS_MIO64
Pin Number
F16
H16
-
F18
D16
-
G18
B16
-
C16
A16
-
F17
J15
-
K15
E17
-
C17
D17
-
A17
E18
-
A18
G19
-
B18
C18
-
E19
