Alinx ACU3EG User Manual page 11

PS_DDR4_DQ18
PS_DDR4_DQ19
PS_DDR4_DQ20
PS_DDR4_DQ21
PS_DDR4_DQ22
PS_DDR4_DQ23
PS_DDR4_DQ24
PS_DDR4_DQ25
PS_DDR4_DQ26
PS_DDR4_DQ27
PS_DDR4_DQ28
PS_DDR4_DQ29
PS_DDR4_DQ30
PS_DDR4_DQ31
PS_DDR4_DQ32
PS_DDR4_DQ33
PS_DDR4_DQ34
PS_DDR4_DQ35
PS_DDR4_DQ36
PS_DDR4_DQ37
PS_DDR4_DQ38
PS_DDR4_DQ39
PS_DDR4_DQ40
PS_DDR4_DQ41
PS_DDR4_DQ42
PS_DDR4_DQ43
PS_DDR4_DQ44
PS_DDR4_DQ45
PS_DDR4_DQ46
PS_DDR4_DQ47
PS_DDR4_DQ48
PS_DDR4_DQ49
PS_DDR4_DQ50
PS_DDR4_DQ51
PS_DDR4_DQ52
PS_DDR4_DQ53
11 / 33
ZYNQ Ultrascale + FPGA Board ACU3EG User Manual
PS_DDR_DQ18_504
PS_DDR_DQ19_504
PS_DDR_DQ20_504
PS_DDR_DQ21_504
PS_DDR_DQ22_504
PS_DDR_DQ23_504
PS_DDR_DQ24_504
PS_DDR_DQ25_504
PS_DDR_DQ26_504
PS_DDR_DQ27_504
PS_DDR_DQ28_504
PS_DDR_DQ29_504
PS_DDR_DQ30_504
PS_DDR_DQ31_504
PS_DDR_DQ32_504
PS_DDR_DQ33_504
PS_DDR_DQ34_504
PS_DDR_DQ35_504
PS_DDR_DQ36_504
PS_DDR_DQ37_504
PS_DDR_DQ38_504
PS_DDR_DQ39_504
PS_DDR_DQ40_504
PS_DDR_DQ41_504
PS_DDR_DQ42_504
PS_DDR_DQ43_504
PS_DDR_DQ44_504
PS_DDR_DQ45_504
PS_DDR_DQ46_504
PS_DDR_DQ47_504
PS_DDR_DQ48_504
PS_DDR_DQ49_504
PS_DDR_DQ50_504
PS_DDR_DQ51_504
PS_DDR_DQ52_504
PS_DDR_DQ53_504
Amazon Store: https://www.amazon.com/alinx
AD25
AD24
AG26
AH25
AH26
AG25
AH27
AH28
AF28
AG28
AC27
AD27
AD28
AC28
T22
R22
P22
N22
T23
P24
R24
N24
H24
J24
M24
K24
J22
H22
K22
L22
M25
M26
L25
L26
K28
L28
