Alinx ACU3EG User Manual page 30

109 505_TX2_P
111 505_TX2_N
113
115 505_RX2_P
117 505_RX2_N
119
Pin assignment of board to board connector J31
J31 Pin Signal Name
1 B24_L10_P
3 B24_L10_N
5
7 B24_L6_P
9 B24_L6_N
11
13 B24_L5_P
15 B24_L5_N
17
19 B24_L1_P
21 B24_L1_N
23
25 B24_L12_P
27 B24_L12_N
29
31 B24_L3_P
33 B24_L3_N
35
37 B44_L12_N
39 B44_L12_P
41
43 B44_L10_N
45 B44_L10_P
47
49 B24_L11_N
30 / 33
ZYNQ Ultrascale + FPGA Board ACU3EG User Manual
C25
C26
GND -
B27
B28
GND -
Pin
Number
Y14
Y13
GND -
AC14
AC13
GND -
AD15
AD14
GND -
AE15
AE14
GND -
Y12
AA12
GND -
AG13
AH13
GND -
AB9
AB10
GND -
Y10
W10
GND -
W11
Amazon Store: https://www.amazon.com/alinx
110 505_RX1_P
112 505_RX1_N
114
116 505_RX0_P
118 505_RX0_N
120
J31 Pin Signal Name
2 B24_L7_P
4 B24_L7_N
6
8 B44_L6_P
10 B44_L6_N
12
14 B44_L7_P
16 B44_L7_N
18
20 B44_L8_N
22 B44_L8_P
24
26 B24_L2_P
28 B24_L2_N
30
32
34
36
38 B44_L9_P
40 B44_L9_N
42
44 B44_L3_P
46 B44_L3_N
48
50 B44_L1_N
D27
D28
GND
F27
F28
GND
Pin Number
AA13
AB13
GND -
AC12
AD12
GND -
AD11
AD10
GND -
AC11
AB11
GND -
AG14
AH14
GND -
- -
- -
GND -
AA11
AA10
GND -
AH12
AH11
GND -
AH10
-
-
