Configure chip pin assignments:
Signal Name
MIO0_QSPI0_SCLK
MIO1_QSPI0_IO1
MIO2_QSPI0_IO2
MIO3_QSPI0_IO3
MIO4_QSPI0_IO0
MIO5_QSPI0_SS_B
16 / 33
ZYNQ Ultrascale + FPGA Board ACU3EG User Manual
Pin Name
PS_MIO0_500
PS_MIO1_500
PS_MIO2_500
PS_MIO3_500
PS_MIO4_500
PS_MIO5_500
Amazon Store: https://www.amazon.com/alinx
Pin Number
AG15
AG16
AF15
AH15
AH16
AD16
