Configuration Chip pin assignment:
Signal Name
MMC_DAT0
MMC_DAT1
MMC_DAT2
MMC_DAT3
MMC_DAT4
MMC_DAT5
MMC_DAT6
MMC_DAT7
MMC_CMD
MMC_CCLK
MMC_RSTN
18 / 33
ZYNQ Ultrascale + FPGA Board ACU3EG User Manual
PS_MIO13_500
PS_MIO14_500
PS_MIO15_500
PS_MIO16_500
PS_MIO17_500
PS_MIO18_500
PS_MIO19_500
PS_MIO20_500
PS_MIO21_500
PS_MIO22_500
PS_MIO23_500
Amazon Store: https://www.amazon.com/alinx
Pin Name
Pin Number
AH18
AG18
AE18
AF18
AC18
AC19
AE19
AD19
AC21
AB20
AB18
