4.2 Connect the Console Load Device
Should the console load device cable be dislodged during ship-
ment, follow these instructions. The CD-ROM drive located at the
top of the storage drawer in the upper left of the system cabinet is
the system load device. It is supported by the KFTIA or a KZPAA
in a PCI I/O subsystem.
Figure 4-3
KFTIA as the Console Load Device Support
Front
4-4 Making Console, SCSI, Ethernet, FDDI, and DSSI Connections
Console Load
Device
SCSI CD-ROM
Connector
Single-Ended
SCSI Port
BX-0606B-94
