SOFTENER INSTALLATION AND USER GUIDE
Drawing Order No.
No.
1 V3858‐01
2 V3866
3 V3865
4 V3867
V4026
V4027
5
6 V3827
7 V3860
8 V3859
9 V3861
10 V3870‐02BOARD SC PCB REPLACE
11 V3917
12 V4068‐01
13 V4069
Not Shown V3864‐01
Not Shown V3868‐01*
Not Shown V3869‐01*
Not Shown V3868‐02
Not Shown V3869‐02
Not Shown V3186‐01
Not Shown V3186‐36
Not Shown V3474
Not Shown V3475‐12
Not Shown V3475‐24
Not Shown V3475‐36
Not Shown V3819**
BARRIE • ONTARIO • CANADA TF: 705.733.8900 WWW.EXCALIBURWATER.COM
Description
SC FIBOX PC 30/25‐3 MACHINED (does not
include strain reliefs)
STRAINRELIEF 1HOLE ASY
STRAINRELIEF 6HOLE ASY
STRAINRELIEF 2HOLE ASY
PUSHBUTTON ACTUATOR
CONTACT BLOCK DPST‐NO, SCREW TERMINAL
SC BRACKET SHEET METAL (does not include standoffs)
STANDOFF #6‐32X1/4 MXF SS
SCREW #4‐24X1/2 TYPE 25 SS TC
SCREW #10‐32X3/8 GREEN ZINC
SCREW PANHD 6‐32X1/4‐BR STGR
SC BEZEL HSYELLOW ASY
DC BATTERY COVER FOR BEZEL
SC POWER CORD 7FT ASY
SC JUMPER WIRE BROWN, 2IN
SC JUMPER WIRE BLUE, 2IN
SC SWITCH POWER WIRE BROWN, 5IN
SC SWITCH POWER WIRE BLUE, 5IN
WS1 AC ADAPTER CORD ONLY 15FT
WS1 AC ADAPTER CORD ONLY 36FT
WS ALT CONNECT CORD 8 FT BLK
WS2H/3 SYSCONNECTCORD 12FT RED
WS2H/3 SYSCONNECT CORD 24FT BL
WS2H/3 SYSCONNECTCORD 36FT YEL
POWER SWITCH RETROFIT KIT
Quantity
V3030 V3030‐01
1 1
5 4
2 2
1 1
1
1
1 1
8 8
4 4
1 1
1 1
12 12
1 1
1 1
1 N/A
N/A 1
N/A 1
N/A 1
N/A 1
Separate Purchase
Separate Purchase
Separate Purchase
Separate Purchase
Separate Purchase
Separate Purchase
Separate Purchase
