No Hard Water Bypass - Excalibur Water Systems Progressive Flow SC1 Series Installation And User Manual

SOFTENER INSTALLATION AND USER GUIDE
No Hard Water Bypass
Drawing
Order No.
No.
1
2
3
4 V3262‐01
5
6
7
8
9 V3506‐01
10
11 V3521FF
12 V3521FM
13
14
15
BARRIE • ONTARIO • CANADA TF: 705.733.8900 WWW.EXCALIBURWATER.COM
Description
V3073 MAV/NOHWBY COVER ASY
V3476 WS MOTOR ASY 8 FT
V3592 SCREW #8‐3/4 PHPN T‐25 SS
WS1.5&2ALT/2BY REDUCGEARCVRASY
V3110 WS1 DRIVE REDUCING GEAR 12X36
V3264 WS2 BYPASS REDUCTION GEAR AXLE
V3527 SCREW 1/4‐20 X 3/4 BHSCS SS
V3072 MAV/NOHWBY 1/125/15 DRIVE ASY
MAV/NOHRD 1/125/15 PISTON
V3074 MAV/NOHWBY 1/125/15 STACK ASY
NOHRD WTR BYPASS BODY ASY F‐F
NOHRD WTR BYPASS BODY ASY F‐M
V3151 WS1 NUT 1 QC
V3150 WS1 SPLIT RING
V3105 O‐RING 215
•Operating Pressures:
20 PSI Minimum / 125 PSI
Maximum
•Operating Temperatures:
40°F Minimum / 110°F Maximum
V3070FF V3070FM
N/A
N/A
N/A
N/A
Quantity
1 1
1 1
3 3
1 1
3 3
3 3
4 4
1 1
1 1
1 1
1 N/A
1
1
1
1
44
