SOFTENER INSTALLATION AND USER GUIDE
Diagnostic Displays
BARRIE • ONTARIO • CANADA TF: 705.733.8900 WWW.EXCALIBURWATER.COM
STEP 1D: ‐ Press UP and DOWN buttons simultaneously for three seconds and
release.
STEP 2D: ‐ Press UP and DOWN to scroll through the last 60 regenerations.
Information displayed includes the unit, day and time of the regeneration. Press
NEXT to go to Step 3D.
STEP 3D: ‐ Press UP or DOWN to view the daily treated water usage for the last
99 days.
Press and hold UP and DOWN on the day's usage to view each day's hourly
system usage to go to step 3DA or Press NEXT to go to Step 4D.
STEP 3DA: ‐ Press UP or DOWN to scroll through the treated water usage for
each hour of the day selected. Press NEXT to go back to Step 3D.
STEP 4D: ‐ Press UP or DOWN to view the maximum flow rate recorded for the
last 99 days. Press UP and DOWN simultaneously to go to Step 4DA or Press
NEXT to go to Step 5D.
STEP 4DA: ‐ Press UP or DOWN to scroll through the maximum flow rate for each
hour of the day selected. Press UP and DOWN buttons simultaneously on the
hour selected to go to next Step 4DB.
