SOFTENER INSTALLATION AND USER GUIDE
Drawing No. Order No.
1
2
V3166‐01 FTG Flow Control Body Female 1
3
4
5
6
7
V3190‐090 WS1 DLFC 9.0 gpm for 1
V3190‐100 WS1 DLFC 10.0 gpm for 1
V3190‐110 WS1 DLFC 11.0 gpm for 1
V3190‐130 WS1 DLFC 13.0 gpm for 1
8
V3190‐150 WS1 DLFC 15.0 gpm for 1
V3190‐170 WS1 DLFC 17.0 gpm for 1
V3190‐200 WS1 DLFC 20.0 gpm for 1
V3190‐250 WS1 DLFC 25.0 gpm for 1
BARRIE • ONTARIO • CANADA TF: 705.733.8900 WWW.EXCALIBURWATER.COM
Drain Line 1"
Description
H4615 Elbow Locking Clip
V3166 WS1 Drain FTG Body 1
V3167 WS1 Drain FTG Adapter 1
V3163 0‐ring 019
V3150 WS1 Split Ring
V3151 WS1 Nut 1" QC
V3105 O‐ring 215
Quantity
1
1
1
1
1
1
1
One DLFC must
be used if 1"
fitting is used
