SOFTENER INSTALLATION AND USER GUIDE
Components of Control Valve
5.3.1) Front Cover and PC Board
Drawing No. Order No.
1 V3175EE‐01
2 V3107‐01
3 V3106‐01
4 V3408EE‐04BOARD WS1THRU/2 EE PCB 5 DIGIT REPL
5 V3110
6 V3109
V3186
Not Shown
V3186‐01
Not Shown V3178
Wiring for Correct On/Off Operation
PC Board Relay Terminal Block
RLY 1
+ COM
Relay Specifications: 12V DC Relay with a coil resistance not less than 80 ohms. If mounting relay under the cover check for
proper mounting dimensions on the backplate.
BARRIE • ONTARIO • CANADA TF: 705.733.8900 WWW.EXCALIBURWATER.COM
Description
WS1EE FRONT COVER ASSEMBLY
WS1 MOTOR
WS1 DRIVE BRACKET & SPRING CLIP
WS1 DRIVE GEAR 12X36
WS1 DRIVE GEAR COVER
WS1 AC ADAPTER 1 20V‐12V
WS1 AC ADAPTER CORD O NLY
WS1 Drive Back Plate
Relay
Coil ‐
Coil +
Quantity
1
1
1
1
3
1
1
1
AC Adapter
Supply Voltage
Supply Frequency 60 Hz
Output Voltage
Output Current
35
U.S.
120 V AC
12 V AC
500 mA
