SOFTENER INSTALLATION AND USER GUIDE
History Displays
BARRIE • ONTARIO • CANADA TF: 705.733.8900 WWW.EXCALIBURWATER.COM
STEP 4DB: ‐ Press UP or DOWN to scroll through the average system flow rate for
the selected hour, in 6‐minute interval. Press NEXT to return to Step 4DA.
STEP 5D: ‐ This display shows the error log with last 20 valve errors and
communication losses are stored in it. Use UP and DOWN buttons to scroll
through the log.
DAY XX = Indicates the number of days ago
COM‐ = Communication lost error
RPTD = Indicates the valve error was not reset
CLRD = Indicates the valve error was finally reset
STEP 6D: ‐ Press UP or DOWN to view the last 20 power events. Press NEXT to
exit Diagnostics. Press REGEN to return to previous step.
STEP 1HD: ‐ Press UP and DOWN simultaneously for three seconds and release.
Again press UP and DOWN buttons simultaneously for three seconds and
release.
STEP 2HD: ‐ Displays software rev level. Press NEXT to go to Step 3HD.
STEP 3HD: ‐ Displays total days since startup. Press NEXT to exit to normal
model.
27
