SOFTENER INSTALLATION AND USER GUIDE
5.3.7) Bypass Valve Components
Drawing No. Order No. Description
1 V3151 WS1 Nut 1" Quick Connect
2 V3150 WS1 Split Ring
3 V3105 O‐Ring 215
4 V3145 WS1 Bypass 1" Rotor
5 V3146 WS1 Bypass Cap
6 V3147 WS1 Bypass Handle
7 V3148 WS1 Bypass Rotor Seal Retainer
8 V3152 O‐ring 135
9 V3155 O‐ring 112
10 V3156 O‐ring 214
BARRIE • ONTARIO • CANADA TF: 705.733.8900 WWW.EXCALIBURWATER.COM
Quantity
2
2
2
2
2
2
2
2
2
2
42
