SUPERIOR SERIES ELECTRONIC
TIMER WATER SOFTENER
Installation Manual
Barrie, Ontario Canada
L4N 4Y8
www.excaliburwater.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Superior Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Excalibur Water Systems Superior Series

  • Page 1 SUPERIOR SERIES ELECTRONIC TIMER WATER SOFTENER Installation Manual Barrie, Ontario Canada L4N 4Y8 www.excaliburwater.com...
  • Page 2: Installation Procedures

    EXCALIBUR SUPERIOR WATER SOFTENER INSTALLATION MANUAL GENERAL WATER SOFTENER INSTALLATION PROCEDURES The Water Softener control valve, fittings and/or bypass Water Softener valve are designed to accommodate minor plumbing misalignments that may occur during the Water Softener installation. Do Not use Vaseline, oils or other hydrocarbon lubricants when installing your Superior Water Softener or spray silicone anywhere.
  • Page 3 WATER SOFTENER INSTALLATION SITE REQUIRMENTS • Water pressure 20 – 125 • Current draw is 0.25 amps • Water temperature 5 to • A 15 foot power cord is 30°C or 40 to 100°F furnished • The Water Softener tank •...
  • Page 4 The Water Softener inlet/outlet plumbing will be installed downstream of outdoor spigots. Install an inlet shutoff valve and plumbing to the Water Softener bypass valve located at the right rear as you face the Water Softener. There are a variety of Water Softener installation fittings available. They are listed under Water Softener installation fitting assemblies.
  • Page 5 a drain tube to its discharge point in accordance with local plumbing codes. Pay special attention to plumbing codes for air gaps and anti-siphon devices. 8. WATER SOFTENER BRINE TANK CONNECTION Install a 3/8 inch outside diameter polyethylene tubing from the Water Softener refill elbow to the brine valve in the Water Softener brine tank.
  • Page 6 WATER SOFTENER SERIAL NUMBER Record the Water Softener serial number on the installer’s records and consumer’s sales invoice. WATER SOFTENER BYPASS VALVE The Water Softener bypass valve is typically used to isolate the Water Softener control valve from the plumbing system, water pressure in order to perform Water Softener control valve repairs or maintenance.
  • Page 7 BYPASS POSITION The inlet and outlet handles point to the centre of the bypass valve. The bypass valve is isolated from the water pressure contained in the plumbing system. Untreated water is supplied to the plumbing system DIAGNOSTIC POSITION The inlet handle points in the direction of water flow and outlet handle points to the centre of the bypass valve.
  • Page 8 SHUTOFF POSITION The inlet handles points to the centre of the bypass valve and the outlet points to the direction of flow. The water is shut off to the plumbing system. If water is available on the outlet side of the Water Softener, it is an indication of water bypass around the system.
  • Page 9 Press and hold the Water Softener UP & DN buttons together for three seconds until the motor drive starts. Wait until the motor stops in the backwash position displaying C1. Open the inlet handle of the bypass valve very slowly allowing water to fill the Water Softener slowly to expel air out the drain line.
  • Page 10 WATER SOFTENER PROGRAMMING SETTINGS Step I Press up & dn buttons simultaneously for 3 seconds Step II Set time of regeneration which will already come factory set for 2:00am. You want to pick a time when the least amount of water is being consumed in the household. Step III: Press the dn button to set the days between regeneration.
  • Page 12: Year Warranty

    Warranty ~ Working Procedures If during the suitable warranty period, a part is defective, then Excalibur Water Systems will repair or replace that part at no charge to the original owner, with the exception of charges for nominal shipping, service and/or installation.
