SOFTENER INSTALLATION AND USER GUIDE
5) CONTROL VALVE
Valve Specifications
Minimum/Maximum Operating Pressures
Minimum/Maximum Operating Temperatures
Power Adapter:
Supply Voltage
Supply Frequency
Output Voltage
Output Current
No user serviceable parts are on the PC board, the motor, or the power adapter. The means of
disconnection from the main power supply is by unplugging the power adapter from the wall.
Service flow rate 1" (includes bypass and meter) 27 gpm (102.2 lpm, 6.1 m3/h) @15 psig (103 kPa) drop
Backwash flow rate 1" (includes bypass)
Minimum/Maximum Operating Pressures
Minimum/Maximum Operating Temperatures
Drain Line Flow Controls
Inlet / Outlet Fitting Options
Distributor Tube Opening WS1 Valve
Tank Thread
Control Valve Weight
PC Board Memory
Compatible with regenerants/chemicals
BARRIE • ONTARIO • CANADA TF: 705.733.8900 WWW.EXCALIBURWATER.COM
20 psi (138 kPa or 1.4 bar) ‐125 psi (862 kPa or 8.6 bar)
40°F (4°C) ‐ 110°F (43°C)
110VAC
60Hz
12VAC
500mA
27 gpm (102.2 lpm, 6.1 m3/h) @25 psig (172 kPa) drop
20 psi (138 kPa) ‐125 psi (862 kPa)
40°F (4°C) ‐ 110°F (43°C)
1" DLFC (V3190‐XX)
See Drawings and Part Numbers
1.05" outside diameter (¾" NPS)
2½" ‐ 8 NPSM
4.5 lbs. (2.0 kg)
Nonvolatile EEPROM
(electrically erasable programmable read only memory)
Sodium chloride, potassium chloride, potassium
permanganate, sodium bisulfite, chlorine and chloramines
