Chapter 3: Configuring the 2085sc-IF8u Using CCW
You may view most of these values using the CCW View Module Profile
General dialog tab:

3.3.5 Connection Types and Assembly Sizes

The size of each assembly is listed in the table below.
These values are stored in the Mod_Size array:
Table
Configuration Assembly
Input Assembly
Output Assembly
Size (Bytes)
32
30
10
User's Manual Pub. 0300305-01 Rev. A
3-11
