Column
#
Name
Value
Units
Internal Value
Default
Min
Max
Chapter 3: Configuring the 2085sc-IF8u Using CCW
5. To copy the generated values into the CCW Configuration: field, click
Copy to CCW. The software copies the configuration and shows it in
the CCW Configuration field.
6. Download and run.
The following description of columns is copied from CCW Help.
Description
Currently selected parameter. As a device is monitored and updated, an
asterisk (*) appears in this column.
Parameter number. Click the column header to list the data in the column in
ascending (default) or descending order.
Short name of the parameter. Click the column header to list the data in the
column in ascending (default) or descending order.
The current value of the parameter. Writable parameter values are shown
with a white background and can be changed directly in this field.
The measurement units used for this parameter (examples: Volts and Amps).
The unscaled value used internally in the device and by AC drives that
communicate with the device. The information in this field provides the
scaling information to calculate Internal Value from a scaled value.
The initial value of a parameter as defined at the factory.
The minimum value is the lowest possible value for this parameter.
The maximum value is the highest possible value for this parameter.

3.3.1 Software Versioning

The software version tracks major and minor revisions for end users.
The shipped software version begins at version 1.1.
Once released, the major revision is typically incremented if new features are
introduced to the product. Otherwise only the minor revision is incremented.

3.3.2 Software Updates

In-field updating of the software by the end user is not supported.

3.3.3 Startup and Factory Default Conditions

After the module boots and before the initial configuration is received, the
User's Manual Pub. 0300305-01 Rev. A
3-9
