Temperature Scale Description; Output Assembly; Module Error - Spectrum Controls 2085sc-IF8U User Manual

The default option is set to use 3-wire measurement with lead wire
compensation.
Voltage/TC Input Current Input
VI-0 VI-0
TC or Voltage
Source
CI-0 CI-0
COM0 COM0
RS0 RS0

3.3.7 Temperature Scale Description

These bits specify the temperature units the module reports in Centigrade or
Fahrenheit. The default setting is Centigrade.

3.3.8 Output Assembly

Tag Name:
Calibration command
Calibration channel
Reserved
Calibration Key I
Calibration Key II

3.3.9 Module Error

The 2085 analog I/O modules notify the host of critical and non-critical module
errors. The controller does not transfer a module specific hardware fault or
configuration fault when using the generic profile. The Mod_Condition Array
Word 0 located in ASIC communication command contains the error codes that
are generated by the modules for indication. 2085 module errors are expressed as
two fields: Mod_Error (3 bits) and Extended_Error_Info (9 bits). This
arrangement was based on 1769 platform.
15 14 13
r r
0 0
Output_State
Mod_Configured
Chapter 3: Configuring the 2085sc-IF8u Using CCW
2-wire Res./RTD Input 3-wire Res./RTD Input
+
VI-0
Jumper
Wire
-
Current
Source
CI-0
+
COM0
RS0
Type:
USINT
USINT
INT
INT
INT
12 11 10 9 8
r r r r r r
0 0 0 0 1 0
Mod_Error
Bus_WD_T imeout_Latch
VI-0
CI-0
COM0
RS0
Offset: Notes:
0×0000
0×0001
0×0002
0×0004 0×06A9
0×0006 0×5C15
7 6 5 4 3 2
r r r r r r
0 0 0 0 0 0
Extended_Error_Info
