Spectrum Controls 2085sc-IF8U User Manual page 43

Input Range
N Thermocouple
R Thermocouple
S Thermocouple
T Thermocouple
100 Ω Pt 0.385
200 Ω Pt 0.385
500 Ω Pt 0.385
1000 Ω Pt 0.385
100 Ω Pt 0.3916
Chapter 3: Configuring the 2085sc-IF8u Using CCW
Input Value Condition
-270.00 °C Low Limit
1300.00 °C High Limit
1300.00 °C High Range
-210.00 °C Low Range
-210.00 °C Low Limit
1768.00 °C High Limit
1768.00 °C High Range
0.00 °C Low Range
0.00 °C Low Limit
1768.00 °C High Limit
1768.00 °C High Range
0.00 °C Low Range
0.00 °C Low Limit
400.00 °C High Limit
400.00 °C High Range
-270.00 °C Low Range
-270.00 °C Low Limit
850.00 °C High Limit
850.00 °C High Range
-200.00 °C Low Range
-200.00 °C Low Limit
850.00 °C High Limit
850.00 °C High Range
-200.00 °C Low Range
-200.00 °C Low Limit
850.00 °C High Limit
850.00 °C High Range
-200.00 °C Low Range
-200.00 °C Low Limit
850.00 °C High Limit
850.00 °C High Range
-200.00 °C Low Range
-200.00 °C Low Limit
630.00 °C High Limit
630.00 °C High Range
-200.00 °C Low Range
EU ×1 EU ×10 Raw Prop
-2700 -270 -32768
13000 1300 32767
13000 1300 32767
-2100 -210 -32768
-2100 -210 -32768
17680 1768 32767
17680 1768 32767
0 0 -32768
0 0 -32768
17680 1768 32767
17680 1768 32767
0 0 -32768
0 0 -32768
4000 400 32767
4000 400 32767
-2700 -270 -32768
-2700 -270 -32768
8500 850 32767
8500 850 32767
-2000 -200 -32768
-2000 -200 -32768
8500 850 32767
8500 850 32767
-2000 -200 -32768
-2000 -200 -32768
8500 850 32767
8500 850 32767
-2000 -200 -32768
-2000 -200 -32768
8500 850 32767
8500 850 32767
-2000 -200 -32768
-2000 -200 -32768
6300 630 32767
6300 630 32767
-2000 -200 -32768
User's Manual Pub. 0300305-01 Rev. A
3-19
Percentage
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
