Spectrum Controls 2085sc-IF8U User Manual page 45

Input Range
0-1000 Ω
0-3000 Ω
±50 mV
±100 mV
±10 V
0-10 V
0-5 V
4-20 mA
0-20 mA
Chapter 3: Configuring the 2085sc-IF8u Using CCW
Input Value Condition
0.00 Ω Low Limit
1000.00 Ω High Limit
1000.00 Ω High Range
0.00 Ω Low Range
0.00 Ω Low Limit
3000.00 Ω High Limit
3000.00 Ω High Range
0.00 Ω Low Range
0.00 Ω Low Limit
52.50 mV dc High Limit
50.00 mV dc High Range
-50.00 mV dc Low Range
-52.50 mV dc Low Limit
105.00 mV dc High Limit
100.00 mV dc High Range
-100.00 mV dc Low Range
-105.00 mV dc Low Limit
10.50 V dc High Limit
10.00 V dc High Range
-10.00 V dc Low Range
-10.50 V dc Low Limit
10.50 V dc High Limit
10.00 V dc High Range
0.00 V dc Low Range
-0.50 V dc Low Limit
5.25 V dc High Limit
5.00 V dc High Range
0.00 V dc Low Range
-0.25 V dc Low Limit
21.00 mA High Limit
20.00 mA High Range
4.00 mA Low Range
3.20 mA Low Limit
21.00 mA High Limit
20.00 mA High Range
EU ×1 EU ×10 Raw Prop
0 0 -32768
10000 1000 32767
10000 1000 32767
0 0 -32768
0 0 -32768
30000 3000 32767
30000 3000 32767
0 0 -32768
0 0 -32768
5250 525 32767
5000 500 31207
-5000 -500 -31208
-5250 -525 -32768
10500 1050 32767
10000 1000 31207
-10000 -1000 -31208
-10500 -1050 -32768
10500 1050 32767
10000 1000 31207
-10000 -1000 -31208
-10500 -1050 -32768
10500 1050 32767
10000 1000 29788
0 0 -29789
-500 -50 -32768
5250 525 32767
5000 500 29788
0 0 -29789
-250 -25 -32768
21000 2100 32767
20000 2000 29085
4000 400 -29823
3200 320 -32768
21000 2100 32767
20000 2000 29646
User's Manual Pub. 0300305-01 Rev. A
3-21
Percentage
0
10000
10000
0
0
10000
10000
0
0
10250
10000
0
-250
10250
10000
0
-250
10250
10000
0
-250
10500
10000
0
-500
10500
10000
0
-500
10625
10000
0
-500
10500
10000
