Input Description
Input protection:
Isolation
Input to backplane isolation
Input to Chassis GND isolation
Channel-to-channel, low-level
isolation
Fault detection
Power Requirements
Bus +5 V (4.75 V to 5.4 V)
Bus +24 V (19.9 V to 26.4 V)
Peak Inrush Current
Power Dissipation within module
Wire size
RoHS
Wire Strip Length
Recommended Tightening
Torque:
REACH
Dimensions
Chapter 1: Module Overview
210 µA
* typically ±5% at 25 °C, ±8% from -20 °C to 65 °C
Voltage Mode ±28 VDC continuous. (Note: maximum voltage
between any two pins must be limited to 28 VDC as well.) For
proper operation, do not connect any external voltages to the
CJC pins.
Current mode 32 mA continuous (approximately 8 V).
50 VAC RMS working Reinforced isolation tested at 2 kVDC
for 1 minute.
50 VAC RMS working Reinforced isolation tested at 2 kVDC
for 1 minute.
10 VDC measured between the IN-leads. Maximum voltage
between any two pins must be limited to 28 VDC. CJC input
pins are not designed to be attached to external voltages.
Over/under range for all types.
Open Circuit detection is supported on all ranges except the 0-20
mA range. You may disable fault detection for volt, millivolt,
and thermocouple measurements.
Note: Voltage and Thermocouple open circuit (open wire) is
periodically checked to keep input impedance high during
normal measurements.
97 mA max
15 mA max
Less than 150 mA at 5 V.
Less than 400 mA at 24 V.
0.9 W maximum in Voltage/TC/Res/RTD modes; 1.8 W
maximum in current mode with all inputs at 21 mA.
#16 to #28 AWG
Meets European RoHS component standards (January 2015 and
earlier).
0.375 in.
0.25 N-m (2.2 lb-in )
Meets European REACH 7 requirements.
110 mm × 87 mm × 51 mm (plastics).
110 mm × 89 mm × 51 mm (with RTBs installed).
Value
3000 Ω, 500 Ω PT 385, 1000 Ω PT
385, 500 Ω PT 3916, 1000 Ω PT
3916, 604 Ω NiFe 518
