3-14
Chapter 3: Configuring the 2085-IT8-SC/IT-16-SC Using CCW
Section 3.5
Software Information
Parameter
Vendor ID
Product Type
Product Code
Series Rev
Module Catalog String 2085-IT8-SC
Table
Configuration Assembly
Input Assembly
Output
User's Manual Pub. 0300322-01 Rev. A
8. Download the CCW project to controller and start to run the module
operation.

3.5.1 Software Versioning

The software version tracks major and minor revisions for end users.
The shipped software version begins at version 1.1.
Once released, the major revision is typically incremented if new features are
introduced to the product. Otherwise only the minor revision is incremented.

3.5.2 Software Updates

In-field updating of the software by the end user is not supported.

3.5.3 Startup and Factory Default Conditions

After the module boots, and before the initial configuration is received, the
module holds the default configuration as specified in the Configuration
Assembly. There is no input data communication and no signal outputting before
the controller goes into run mode. The initial configuration assumes a default
configuration of Type J TC and the 17 Hz filter using the Engineering Unit ×1
setup.
Module Identity
The following values will be stored in the Vendor ID, Product_Type,
Product_Code, Series_Rev, and Mod_Features arrays:
2085-IT8-SC
58 (Spectrum Controls) [0×03A]
10 (Analog) [0×0A]
117
50208 [0×C420] (First release
revision is 1.1)

3.5.4 Connection Types and Assembly Sizes

The size of each assembly is listed in the table below. Each word takes 2 bytes.
These values are stored in the Mod_Size array:
2085-IT16-SC
58 (Spectrum Controls) [0×03A]
10 (Analog) [0×0A]
118
50208 [0×C420] (First release
revision is 1.1)
2085-IT16-SC
2085-IT8-SC
2085-IT16-SC
Size (words)
Size (words)
32
64
17
29
2
2
