Mod_Error Extended_Error_Info(8:0)
(11:9)
0×2 0×000–0×007
0×2 0×010–0×017
0×2 0×100

Section 3.4 Technical Assistance

Section 3.5 Declaration of
Conformity
6
The last 4 bits of Extended_Error_info indicate Channel number for 0 to 7.
7
Invalid Input Range selection Channel n: Check the Input Range setting from the Channel Configuration data.
Invalid range values will cause a configuration error, like open-circuit detection is disabled other than volt, millivolt,
and thermocouple range types.
8
The given information of module configuration table size filled in the RSLogix or CCW program is incorrect.
Chapter 3: Configuring the 2085sc-IF8u Using CCW

3.3.12 Module Specific Configuration Errors

Note that your module contains electronic components which are susceptible to
damage from electrostatic discharge (ESD). An electrostatic charge can
accumulate on the surface of ordinary plastic wrapping or cushioning material. In
the unlikely event that the module should need to be returned to Spectrum
Controls, please ensure that the unit is enclosed in approved ESD packaging
(such as static-shielding / metalized bag or black conductive container).
Spectrum Controls reserves the right to void the warranty on any unit that is
improperly packaged for shipment.
RMA (Return Merchandise Authorization) form required for all product returns.
For further information or assistance, please contact your local distributor, or call
the Spectrum Controls technical Support at:
For Rockwell Automation Compatible I/O Products:
USA
United Kingdom
Australia
Mexico
Brazil
Europe
Available upon request
Error Description
General Config Error: no additional
6
information.
Invalid Input Range selection Channel 0–7.
Given configuration table size is incorrect.
440-646-6900
01908 635230
1800-809-929
001-888-365-8677
(55) 11 3618 8800
+49 211 41553 630
User's Manual Pub. 0300305-01 Rev. A
3-25
