Tag Name:
Ch3Status
Ch4Status
Ch5Status
Ch6Status
Ch7Status
Module Status
CJC Fault
CJC Under Range
CJC Over Range
CJC Open Circuit
CJC Data Not Ready UINT
Cal Data Checksum
Invalid
SN Checksum
Invalid
Reserved
Module Fault
Firmware Revision:
Minor
Firmware Revision:
Major
Chapter 3: Configuring the 2085sc-IF8u Using CCW
Type: Offset: Notes:
USINT 0×0015 Channel 3 Status (as above)
USINT 0×0016 Channel 4 Status (as above)
USINT 0×0017 Channel 5 Status (as above)
USINT 0×0018 Channel 6 Status (as above)
USINT 0×0019 Channel 7 Status (as above)
UINT 0×001A
UINT 0×001A Bit 0. CJC Status. This bit is set when the CJC sensor has
Open Circuit, Data Error, Data Not Ready or Under/Over
range fault.
UINT 0×001A Bit 1. Cold Junction Sensor Signal under range.
UINT 0×001A Bit 2. Cold Junction Sensor Signal over range.
UINT 0×001A Bit 3. Cold Junction Sensor Open Circuit.
0×001A Bit 4. Initial sampling. Data not ready.
UINT 0×001A Bit 5. Cal Data Checksum Invalid. MFG usage only.
UINT 0×001A Bit 6. Serial Number Checksum Invalid. MFG usage only.
UINT 0×001A Bit 7 -14.
UINT 0×001B Bit 15. Module fault if any channel fault or CJC fault.
USINT 0×001C Firmware revision information, minor (RA requirement).
USINT 0×001D Firmware revision information, major (RA requirement).
Channel Enable or Disable Description
Specify whether to enable use of each selected channel. Each channel is Enabled
by default (checkmark selected).
