3-20 Chapter 3: Configuring the 2085sc-IF8u Using CCW
Input Range
200 Ω Pt 0.3916
500 Ω Pt 0.3916
1000 Ω Pt 0.3916
10 Ω Cu 0.426
100 Ω Ni 0.618
120 Ω Ni 0.672
604 Ω Ni-Fe 0.518
0-150 Ω
0-500 Ω
User's Manual Pub. 0300305-01 Rev. A
Input Value Condition
-200.00 °C Low Limit
630.00 °C High Limit
630.00 °C High Range
-200.00 °C Low Range
-200.00 °C Low Limit
630.00 °C High Limit
630.00 °C High Range
-200.00 °C Low Range
-200.00 °C Low Limit
630.00 °C High Limit
630.00 °C High Range
-200.00 °C Low Range
-200.00 °C Low Limit
260.00 °C High Limit
260.00 °C High Range
-100.00 °C Low Range
-100.00 °C Low Limit
260.00 °C High Limit
260.00 °C High Range
-100.00 °C Low Range
-100.00 °C Low Limit
260.00 °C High Limit
260.00 °C High Range
-80.00 °C Low Range
-80.00 °C Low Limit
200.00 °C High Limit
200.00 °C High Range
-100.00 °C Low Range
-100.00 °C Low Limit
150.00 Ω High Limit
150.00 Ω High Range
0.00 Ω Low Range
0.00 Ω Low Limit
500.00 Ω High Limit
500.00 Ω High Range
0.00 Ω Low Range
EU ×1 EU ×10 Raw Prop
-2000 -200 -32768
6300 630 32767
6300 630 32767
-2000 -200 -32768
-2000 -200 -32768
6300 630 32767
6300 630 32767
-2000 -200 -32768
-2000 -200 -32768
6300 630 32767
6300 630 32767
-2000 -200 -32768
-2000 -200 -32768
2600 260 32767
2600 260 32767
-1000 -100 -32768
-1000 -100 -32768
2600 260 32767
2600 260 32767
-1000 -100 -32768
-1000 -100 -32768
2600 260 32767
2600 260 32767
-800 -80 -32768
-800 -80 -32768
2000 200 32767
2000 200 32767
-1000 -100 -32768
-1000 -100 -32768
15000 1500 32767
15000 1500 32767
0 0 -32768
0 0 -32768
5000 500 32767
5000 500 32767
0 0 -32768
Percentage
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
0
10000
10000
0
