GE
D
5273008-100, R
IRECTION
4-3-6
B Mode Checks
4-3-6-1
Preparations
1.) Connect one of the probes listed in
to the System probe connector.
2.) Turn ON the scanner (if it isn't turned on already).
SoftMenu Key
Frequency
Virtual Convex
Edge Enhance
Colorize
Dynamic Range
Gray Map
Rotation
Rejection
Focus Position
Focus Number
B Mode
Zoom
9
EVISION
Figure 4-8 Controls available in B Mode
Figure 4-9 B Mode Screen Picture Example
Chapter 4 Functional Checks
LOGIQ C S
3-6-6 "Available Probes" on page
B
S
M
ERIES
ASIC
ERVICE
ANUAL
3-18, in Chapter 3 Installation
Secondary Menu
Biopsy Kit
Frame Average
Line Density
Focus Width
B softener
Power Output
Suppression
Range Focus
TGC
Depth
Scan Area
Freeze
4 - 9
