3-6-5-5 Connect Peripherals
A.) Connect B/W printer to the system.
B/W Printer can be properly connected using USB Ports.
B.) Connect UP-D23 color printer to the system. (Only supported by LOGIQ C5/C5 PRO)
UP-D23 Color Printer can be properly connected using USB Ports.
9
EVISION
Figure 3-9 Connect B/W printer to the system
Figure 3-10 Connect color printer to the system
