Setting the Print or Store Key to USB Quick Save

If the Print or Store Key is not set to screen capture:
1.) While on the Connect screen, with the Buttons tab displayed, go to the Destinations list.
2.) From the list select USB Quick Save. Press [>>] to add the selection to the Printflow View
3.) Ensure that the Physical Print Buttons section for capture Area is set to Image Area and No
4.) The Print and Store Key should now be set up for USB Quick Save, sending the images directly
It is unable to get full screen using USB Quick Save, just Image Area is available.
NOTICE
9
EVISION
section.
Image Compression.
to the USB memory.
