Section 3-3

Receiving and Unpacking the Equipment

When a new system arrives, check that any components are not damaged and are not in short supply.
If shipping damage or shortage occurs, contact the address shown in Chapter 1.
Do not lift the unit by the Keyboard. Equipment damage may result.
CAUTION
The crate with the LOGIQ C Series weighs approximately 75kg. Be prepared for a sudden shift
CAUTION
of weight as the unit is removed from its base (pallet)
Unpacking the the equipment
1.) Remove all the strapping tapes from the packing box.
2.) Remove the upper cover of the packing box and then rotate the knob to the right to open the
3.) Remove the PE bag and plastic film from the system.
4.) Remove Accessories Carton from the system.
5.) Remove the PE bag and plastic film from the syste
6.) Lift down the system .
9
EVISION
packing box.
Figure 3-2 Open the box
