GE
D
5273008-100, R
IRECTION
7-6-1-1
Wire-LAN Network (cont'd)
NOTE:
If user want to setup static IP address, uncheck Enable DHCP option, input static address in IP-
Address box, Subnet Mask and Default Gateway box. In Network Speed box, choose the proper
speed available.
3.) Click Save, in popped-up dialog choose Shutdown.
4.) After the system shutdown, reboot the system.
5.) After reboot, the network icon at the left bottom of screen turns green.
9
EVISION
Figure 7-7 Input static address
Figure 7-8 Save and reboot inquiry dialog
Figure 7-9 Network icon
Section 7-6 - Network Configuration
LOGIQ C S
B
S
ERIES
ASIC
M
ERVICE
ANUAL
7 - 13
