2.4.1 Minimum Spacing

6
5
Description
1
Mounting screw hole/mounting foot
2
Removable Terminal Block (RTB)
3
RTB hold down screws
User's Manual Pub. 0300306-01 Rev. A
Maintain spacing from enclosure walls, wireways, adjacent equipment, etc.
Allow 50.8 mm (2 in.) of space on all sides for adequate ventilation, as shown:

2.4.2 Parts List

Your package contains one Micro850 2085sc-IF16C or 2085sc-IF16V Plug-in
Module and one Quick Start Guide.
2.4.3 Module Description
3
3
1

2.4.1 Insert Module into the Controller

You can choose to wire the plug-in before inserting it into the controller, or wire
2
Description
4
Module interconnect latch
5
DIN rail mounting latch
6
I/O Status LED
3
4
1
