Mod_Err
Extended_Error_Info [8:0]
or [11:9]
Reserve
(binary)
d [8]
(binary)
010
0
010
0
Chapter 3: Configuring the 2085sc-IF16 Using CCW
Error
Channel
[7:4]
[3:0] (binary)
(binary)
0100
0000–1111
0101
0000–1111
Combined
Description
[11:0]
(hex)
Alarm Not Enabled
440–44f
Check the Channel Enable, Process
Alarm Enable, and Process Alarm
Latch bits in the Channel
Configuration data. This error
occurs if the channel is enabled and
the Process Alarm Latch bit is set,
but the Process Alarm Enable bit is
not set.
Invalid Alarm Data
450–45f
Check the Process Alarm Low
Value and Process Alarm High
Value for legal ranges. If the
module receives any of the
following illegal data, this error is
detected:
Range Max < AHV
Range Min > ALV
AHV <= ALV
ALV is the Process Alarm Low
Value
AHV is the Process Alarm High
Value
Range Max and Range Min are the
full scale values for the selected
Input Range and Input Data
Formats.
User's Manual Pub. 0300306-01 Rev. A
3-23
