16-channel analog input module
Table of Contents

Advertisement

Input Description
Fault detection
Wire size
Wire Strip Length
Recommended Tightening
Torque:
RoHS
REACH
Dimensions
Environmental Tests
Temperature (Operating)
(Performance Criteria A)
Temperature
(Non-operating)
(Performance Criteria B)
Operating Altitude
Humidity (Operating)
(Performance Criteria A)
Vibration (Operating)
(Performance Criteria A)
Shock (Operating)
(Performance Criteria A)
Shock (Non-operating)
(Performance Criteria B)
Radiated Emissions
Conducted Emissions
Chapter 1: Module Overview
Over/under range for all types.
Open Circuit detection is supported on all ranges except the 0-20
mA range.
Note: Voltage open circuit (open wire) is periodically checked
to keep input impedance high during normal measurements.
#16 to #28 AWG
0.375 in.
0.25 N-m (2.2 lb-in)
Meets European RoHS component standards (January 2015 and
earlier).
Meets European REACH 7 requirements.
110 mm × 87 mm × 51 mm (plastics)
110 mm × 89 mm × 51 mm (with RTBs installed.)
Table 1-2. Environmental Specification Table
Industry Standards
IEC60068-2-1: (Test Ad, Operating Cold),
IEC60068-2-2: (Test Bd, Operating Dry Heat),
IEC60068-2-14: (Test Nb, Operating Thermal Shock)
IEC60068-2-1:
(Test Ab, Unpackaged Non-operating Cold),
IEC60068-2-2:
(Test Bb, Unpackaged Non-operating Dry Heat),
IEC60068-2-14:
(Test Nb, Unpackaged Non-operating Thermal Shock)
2000 meters (6561 feet)
IEC60068-2-30:
(Test Db, Unpackaged Damp Heat):
IEC60068-2-6: (Test Fc, Operating)
IEC60068-2-27: (Test Ea, Unpackaged Shock)
IEC60068-2-27: (Test Ea, Unpackaged Shock)
IEC 61000-6-4:2007 (CISPR 11)
IEC 61000-6-4:2007 (CISPR 11)
Value
User's Manual Pub. 0300306-01 Rev. A
1-5
