2-4
Chapter 2: Installation and Wiring
Section 2.4
Mounting
WARNING
6
5
User's Manual Pub. 0300306-02 Rev. B
Keeping module free of debris and avoiding overheating:
Do not remove protective debris strip until after the module and
all other equipment near the module is mounted and the wiring is
complete.
Once wiring is complete, and the module is free of debris,
carefully remove protective strip.
Failure to remove strip before operating can cause overheating.

2.4.1 Minimum Spacing

Maintain spacing from enclosure walls, wireways, adjacent equipment, etc.
Allow 50.8 mm (2 in.) of space on all sides for adequate ventilation, as shown:

2.4.2 Parts List

Your package contains one Micro800 2085sc-IF16C or 2085sc-IF16V Plug-in
Module and one Quick Start Guide.

2.4.3 Module Description

3
3
1
2
3
4
1
